PRECISION GRINDING
PRECISION GRINDING WHEEL
– Type 2 –
| Diameter D (mm) | Thickness T (mm) | Bore H (mm) |
| 200 | 100 | 150 |
| 250 | 100 | 200 |
| 300 | 100 | 250 |
| 450 | 150 | 380 |
PRECISION GRINDING WHEEL
– Type 3 –
| Diameter D (mm) | Thickness T (mm) | Bore H (mm) |
| 150 | 10-13 | 25-32 |
| 175 | 10-13 | 25-32 |
| 200 | 13-16 | 25-32 |
| 250 | 13-16 | 25-32 |
| 300 | 13-20 | 127 |
| 350 | 25-50 | 127 |
| 400 | 13-63 | 127-203 |
| 450 | 50-63 | 203 |
| 500 | 25-60 | 203 |
| 600 | 25-40 | 305 |
| 750 | 50 | 305 |
PRECISION GRINDING WHEEL
– Type 1-C –
| Diameter D (mm) | Thickness T (mm) | Bore H (mm) |
| 150 | 10-13 | 25-32 |
| 175 | 10-13 | 25-32 |
| 200 | 13-16 | 25-32 |
| 250 | 13-16 | 25-32 |
| 300 | 13-20 | 127 |
| 350 | 25-50 | 127 |
| 400 | 13-63 | 127-203 |
| 450 | 50-63 | 203 |
| 500 | 25-60 | 203 |
| 600 | 25-40 | 305 |
| 750 | 50 | 305 |
PRECISION GRINDING WHEEL
– Type 12 –
| Diameter D (mm) | Thickness T (mm) | Bore H (mm) |
| 100 | 10 | 20 |
| 125 | 13 | 20-32 |
| 150 | 16 | 32 |
| 175 | 16-20 | 32 |
| 200 | 20 | 32 |
| 250 | 25 | 32 |
| 300 | 20 | 75-127 |
| 350 | 25-27 | 35-127 |
| 400 | 20-25 | 127 |
| 450 | 29 | 127 |
| 500 | 32 | 203 |
| 600 | 32 | 203 |
| 800 | 35 | 400 |
PRECISION GRINDING WHEEL
– Type 1-F –
| Diameter D (mm) | Thickness T (mm) | Bore H (mm) |
| 145 | 4.7-3 | 22.3 |
| 200 | 13-20 | 32 |
| 350 | 20-32 | 127 |
| 500 | 30-38 | 203 |
| 600 | 28-40 | 203 |
PRECISION GRINDING WHEEL
– Type 5-F –
| Diameter D (mm) | Thickness T (mm) | Bore H (mm) |
| 145 | 4.7-3 | 22.3 |
| 200 | 13-20 | 32 |
| 350 | 20-32 | 127 |
| 500 | 30-38 | 203 |
| 600 | 28-40 | 203 |
PRECISION GRINDING WHEEL
– Type 23 –
| Diameter D (mm) | Thickness T (mm) | Bore H (mm) |
| 250 | 40 | 75 |
| 300 | 40-50 | 127 |
| 350 | 40-63 | 127 |
| 400 | 40-75 | 203 |
| 450 | 75 | 254 |
| 500 | 50 | 203 |
| 600 | 75 | 305 |
| 750 | 50-75 | 305 |
PRECISION GRINDING WHEEL
– Type 26 –
| Diameter D (mm) | Thickness T (mm) | Bore H (mm) |
| 150 | 25 | 32 |
| 200 | 20 | 32 |
| 300 | 40-50 | 75 |
| 400 | 50 | 203 |
| 500 | 63-75 | 305 |
| 600 | 63-75 | 305 |
| 750 | 63-75 | 305 |
| 900 | 63-100 | 305 |
| 1000 | 100 | 305 |
PRECISION GRINDING WHEEL
– Type 7-J –
| Diameter D (mm) | Thickness T (mm) | Bore H (mm) |
| 350 | 13-40 | 75-127 |
| 400 | 10-63 | 127-203 |
| 450 | 40 | 127-203 |
| 500 | 10-75 | 127-305 |
PRECISION GRINDING WHEEL
– Type 8 –
| Diameter D (mm) | Thickness T (mm) | Bore H (mm) |
| 150 | 10-16 | 16-32 |
| 175 | 16-40 | 16-75 |
| 200 | 20-40 | 16-75 |
| 250 | 6-32 | 16-75 |
| 300 | 10-50 | 32-127 |
PRECISION GRINDING WHEEL
– Type 10 –
| Diameter D (mm) | Thickness T (mm) | Bore H (mm) |
| 180 | 6 | 32 |
| 250 | 12 | 75 |
| 350 | 26 | 127 |
| 380 | 40 | 127 |
| 400 | 50 | 127-203 |
PRECISION GRINDING WHEEL
– Type 14-A –
| Diameter D (mm) | Thickness T (mm) | Bore H (mm) |
| 100 | 20-25 | 20 |
| 150 | 30 | 20 |
